Ordinal English Text Description Source
440 SBO Closed Org 4
Select Before Operate (SBO) closing function for organ
4 (interlocking facility in the IEC60870-5-103 protocol)
PSL
468 Fault_REC_TRIG Trigger for Fault Recorder FRT
469 Battery Fail Alarm battery fail PSL(OUT)
470 Field Volt Fail
Field voltage failure (the internal 48 Vdc delivered by the
relay can be used for opto input polarisation)
PSL(OUT)
471 Comm2 H/W FAIL Alarm second rear port PSL(OUT)
472
GOOSE IED
Absent
Absence of GOOSE message from dedicated IED PSL(OUT)
473 NIC Not Fitted Ethernet (board not fitted) alarm PSL(OUT)
474 NIC No Response No response from Ethernet Board alarm. PSL(OUT)
475 NIC Fatal Error Fatal Error from Ethernet Board alarm PSL(OUT)
476 NIC Soft. Reload Ethernet Board (Configuration in progress) alarm PSL(OUT)
477 Bad TCP/IP Cfg. Bad configuration TCP/IP Address alarm PSL(OUT)
478 Bad OSI Config. Ethernet alarm PSL(OUT)
479 NIC Link Fail Ethernet Link Fail alarm PSL(OUT)
480 NIC SW Mis-Match Not compatible Ethernet version alarm PSL(OUT)
481 IP Addr Conflict Ethernet IP Address Conflict alarm PSL(OUT)
482 IM Loopback
InterMiCOM indication that loopback testing is in
progress
PSL(OUT)
483 IM Message Fail InterMiCOM message failure alarm PSL(OUT)
484 IM Data CD Fail InterMiCOM data channel detect fail PSL(OUT)
485 IM Channel Fail InterMiCOM message channel fail PSL(OUT)
486 Back Up Setting Back up setting alarm PSL(OUT)
487 to
511
-- Unused PSL
512 Virtual output 1
Goose output n° 1 - Allows user to control a binary
signal which can be mapped via SCADA protocol output
to other devices
PSL
513 to
543
Virtual output 2
Virtual output 32
Goose output n° 2 to
Goose output n° 32
PSL
576 InterMiCOM in 1
InterMiCOM IM1 Signal Input - is driven by a message
from the remote line end
SW
577 to
583
InterMiCOM in 2 to
InterMiCOM in 8
InterMiCOM IM2 Signal Input to
InterMiCOM IM8 Signal Input
SW
584 InterMiCOM out 1
InterMiCOM IM1 Signal output - mapping what will be
sent to the remote line end
PSL
585 to
591
InterMiCOM out 2
to
InterMiCOM out 8
InterMiCOM IM2 Signal output to
InterMiCOM IM8 Signal output
PSL
592 to
607
-- Unused PSL
608 Control input 1
Control Input 1 - for SCADA and menu commands into
PSL
SW
609 to
639
Control input 2 to
Control input 32
Control input 2 to
Control input 32
SW
640 LED 1 Red
Hardware version K - Programmable Red LED n° 1 is
energized.
ANY TRIP A in the default PSL
SW
640 LED 1
Hardware version J - Programmable LED n° 1 is
energized.
SW
641 LED 1 Grn
Hardware version K - Programmable Green LED n° 1 is
energized
ANY TRIP A in the default PSL
SW
