Ordinal English Text Description Source
641 LED 2
Hardware version J - Programmable LED n° 2 is
energized.
SW
642 LED 2 Red
Hardware version K - Programmable Red LED n° 2 is
energized
ANY TRIP B in the default PSL
SW
642 LED 3
Hardware version J - Programmable LED n° 3 is
energized.
SW
643 LED 2 Grn
Hardware version K - Programmable Green LED n° 2 is
energized
ANY TRIP B in the default PSL
SW
643 LED 4
Hardware version J - Programmable LED n° 4 is
energized.
SW
644 LED 3 Red
Hardware version K - Programmable Red LED n° 3
ANY TRIP C in the default PSL
SW
644 LED 5
Hardware version J - Programmable LED n° 5 is
energized.
SW
645 LED 3 Grn
Hardware version K - Programmable Green LED n° 3
ANY TRIP C in the default PSL
SW
645 LED 6
Hardware version J - Programmable LED n° 6 is
energized.
SW
646 LED 4 Red
Hardware version K - Programmable Red LED n° 4
General Start in the default PSL
SW
646 LED 7
Hardware version J - Programmable LED n° 7 is
energized.
SW
647 LED 4 Grn
Hardware version K - Programmable Green LED n° 4
General Start in the default PSL
SW
647 LED 8
Hardware version J - Programmable LED n° 8 is
energized.
PSL
648 LED 5 Red
Hardware version K - Programmable Red LED n° 5
Z1+Aided Trip in the default PSL
SW
648 to
655
-- Hardware version J – Unused
649 LED 5 Grn
Hardware version K - Programmable Green LED n° 5
Z1+Aided Trip in the default PSL
SW
650 LED 6 Red
Hardware version K - Programmable Red LED n° 6
Dist Fwd in the default PSL
SW
651 LED 6 Grn
Hardware version K - Programmable Green LED n° 6
Dist Fwd in the default PSL
SW
652 LED 7 Red
Hardware version K - Programmable Red LED n° 7
Dist Rev in the default PSL
SW
653 LED 7 Grn
Hardware version K - Programmable Green LED n° 7
Dist Rev in the default PSL
SW
654 LED 8 Red
Hardware version K - Programmable Red LED n° 8
Autoreclose Enable in the default PSL
SW
655 LED 8 Grn
Hardware version K - Programmable Green LED n° 8
Autoreclose Enable in the default PSL
SW
656 LED 9 Red Hardware version K - Programmable Red LED n° 9 SW
656 LED Cond IN 1
Hardware version J - Assignment of signal to drive
output Function Key LED 1
PSL
657 LED 9 Grn Hardware version K - Programmable Green LED n° 9 SW
657 LED Cond IN 2
Hardware version J - Assignment of signal to drive
output Function Key LED 2
PSL
658 LED 10 Red Hardware version K - Programmable Red LED n° 10 SW
658 LED Cond IN 3
Hardware version J - Assignment of signal to drive
output Function Key LED 3
PSL
659 LED 10 Grn Hardware version K - Programmable Green LED n° 10 SW
