P44x/EN PL/Hb
MiCOM 40 Agile P442, P444
(PL) 6-
Ordinal English Text Description Source
659 LED Cond IN 4
Hardware version J - Assignment of signal to drive
output Function Key LED 4
PSL
660 LED 11 Red Hardware version K - Programmable Red LED n° 11 SW
660 LED Cond IN 5
Hardware version J - Assignment of signal to drive
output Function Key LED 5
PSL
661 LED 11 Grn Hardware version K - Programmable Green LED n° 11 SW
661 LED Cond IN 6
Hardware version J - Assignment of signal to drive
output Function Key LED 6
PSL
662 LED 12 Red Hardware version K - Programmable Red LED n° 12 SW
662 LED Cond IN 7
Hardware version J - Assignment of signal to drive
output Function Key LED 6
PSL
663 LED 12 Grn Hardware version K - Programmable Green LED n° 12 SW
663 LED Cond IN 8
Hardware version J - Assignment of signal to drive
output Function Key LED 7
PSL
664 LED 13 Red Hardware version K - Programmable Red LED n° 13 SW
664 to
685
-- Hardware version J – Unused
665 LED 13 Grn Hardware version K - Programmable Green LED n° 13 SW
666 LED 14 Red Hardware version K - Programmable Red LED n° 14 SW
667 LED 14 Grn Hardware version K - Programmable Green LED n° 14 SW
668 LED 15 Red Hardware version K - Programmable Red LED n° 15 SW
669 LED 15 Grn Hardware version K - Programmable Green LED n° 15 SW
670 LED 16 Red Hardware version K - Programmable Red LED n° 16 SW
671 LED 16 Grn Hardware version K - Programmable Green LED n° 16 SW
672 LED 17 Red Hardware version K - Programmable Red LED n° 17 SW
673 LED 17 Grn Hardware version K - Programmable Green LED n° 17 SW
674 LED 18 Red Hardware version K - Programmable Red LED n° 18 SW
675 LED 18 Grn Hardware version K - Programmable Green LED n° 18 SW
676 Function Key 1
Hardware version K - Programmable Function key n° 1.
In ‘Normal’ mode it is high on key press and in ‘Toggle’
mode remains high/low on single key press
SW
677 to
685
Function Key 2 to
Function Key 10
Hardware version K - Function key n° 2 to
Function key n° 10
SW
686 to
699
-- Unused PSL
700 to
763
Output cond. 1 to
Output cond. 64
Input to Relay Output Conditioner PSL
764 to
799
-- Hardware version J – Unused
764 LED 1 Red Condit
Hardware version K - Assignment of signal to drive
output LED 1 red - To drive LED1 Yellow DDB 764 and
DDB 765 must be driven at the same time
PSL
765 LED 1 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 1 green
PSL
766 LED 2 Red Condit
Hardware version K - Assignment of signal to drive
output LED 2 red
PSL
767 LED 2 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 2 green
PSL
768 LED 3 Red Condit
Hardware version K - Assignment of signal to drive
output LED 3 red
PSL
769 LED 3 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 3 green
PSL
770 LED 4 Red Condit
Hardware version K - Assignment of signal to drive
output LED 4 red
PSL
