P
44x/EN PL/Hb6
Programmable Logic
(PL) 6
-22 MiCOM 40 Agile
P442, P444
Ordinal English Text Description Source
771 LED 4 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 4 green
PSL
772 LED 5 Red Condit
Hardware version K - Assignment of signal to drive
output LED 5 red
PSL
773 LED 5 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 5 green
PSL
774 LED 6 Red Condit
Hardware version K - Assignment of signal to drive
output LED 6 red
PSL
775 LED 6 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 6 green
PSL
776 LED 7 Red Condit
Hardware version K - Assignment of signal to drive
output LED 7 red
PSL
777 LED 7 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 7 green
PSL
778 LED 8 Red Condit
Hardware version K - Assignment of signal to drive
output LED 8 red
PSL
779 LED 8 Grn Condit
Hardware version K - Assignment of signal to drive
output LED 8 green
PSL
780 FnKey LED 1 Red
Hardware version K - Assignment of signal to drive
output Function Key LED 1 Red - This LED is associated
with Function Key 1
PSL
781 FnKey LED 1 Grn
Hardware version K - Assignment of signal to drive
output Function Key LED 1 Green - This LED is
associated with Function Key 1 - To drive function key
LED, yellow DDB 780 and DDB 782 must be active at
the same time
PSL
782 FnKey LED 2 Red
Hardware version K - Assignment of signal to drive
output Function Key LED 2 Red
PSL
783 FnKey LED 2 Grn
Hardware version K - Assignment of signal to drive
output Function Key LED 2 Green
PSL
784 FnKey LED 3 Red
Hardware version K - Assignment of signal to drive
output Function Key LED 3 Red
PSL
785 FnKey LED 3 Grn
Hardware version K - Assignment of signal to drive
output Function Key LED 3 Green
PSL
786 FnKey LED 4 Red
Hardware version K - Assignment of signal to drive
output Function Key LED 4 Red
PSL
787 FnKey LED 4 Grn
Hardware version K - Assignment of signal to drive
output Function Key LED 4 Green
PSL
788 FnKey LED 5 Red
Hardware version K - Assignment of signal to drive
output Function Key LED 5 Red
PSL
789 FnKey LED 5 Grn
Hardware version K - Assignment of signal to drive
output Function Key LED 5 Green
PSL
790 FnKey LED 6 Red
Hardware version K - Assignment of signal to drive
output Function Key LED 6 Red
PSL
791 FnKey LED 6 Grn
Hardware version K - Assignment of signal to drive
output Function Key LED 6 Green
PSL
792 FnKey LED 7 Red
Hardware version K - Assignment of signal to drive
output Function Key LED 7 Red
PSL
793 FnKey LED 7 Grn
Hardware version K - Assignment of signal to drive
output Function Key LED 7 Green
PSL
794 FnKey LED 8 Red
Hardware version K - Assignment of signal to drive
output Function Key LED 8 Red
PSL
795 FnKey LED 8 Grn
Hardware version K - Assignment of signal to drive
output Function Key LED 8 Green
PSL
796 FnKey LED 9 Red
Hardware version K - Assignment of signal to drive
output Function Key LED 9 Red
PSL
797 FnKey LED 9 Grn
Hardware version K - Assignment of signal to drive
output Function Key LED 9 Green
PSL
