P44x/EN PL/Hb
MiCOM 40 Agile P442, P444
(PL) 6-
Ordinal English Text Description Source
798 FnKey LED 10 Red
Hardware version K - Assignment of signal to drive
output Function Key LED 10 Red
PSL
799 FnKey LED 10 Grn
Hardware version K - Assignment of signal to drive
output Function Key LED 10 Green
PSL
800 to
829
-- Unused PSL
830 to
845
Timer in 1 to
Timer in 16
Hardware version K - PSL Input to Auxiliary Timer 1
to PSL Input to Auxiliary Timer 16
Auxiliary
Timer
830 to
861
Timer in 1 to
Timer in 16
Hardware version J - PSL Input to Auxiliary Timer 1
to PSL Input to Auxiliary Timer 32
Auxiliary
Timer
846 to
861
Timer out 1 to
Timer out 16
Hardware version K - PSL Ouput from Auxiliary Timer 1
PSL Ouput from Auxiliary Timer 16
Auxiliary
Timer
862 to
893
Timer in 1 to
Timer in 16
Hardware version J - PSL Output from Auxiliary Timer 1
to PSL Output from Auxiliary Timer 32
Auxiliary
Timer
862 to
893
-- Hardware version K - Unused PSL
894 to
922
-- Unused PSL
923 to
1023
Can be created automatically by the PSL PSL
1024 Trip LED LED trip
1025 CB Aux A (52-A)
Circuit breaker pole A closed
(status input from CB, 52-A = normally open)
PSL (IN)
CB STATUS
1026 CB Aux A (52-B)
Circuit breaker pole A open
(Status input from CB, 52-B = normally closed)
PSL (IN)
CB STATUS
1027 CB Aux B (52-A)
Circuit breaker pole B closed
(status input from CB, 52-A = normally open)
PSL (IN)
CB STATUS
1028 CB Aux B (52-B)
Circuit breaker pole B open
(Status input from CB, 52-B = normally closed)
PSL (IN)
CB STATUS
1029 CB Aux C (52-A)
Circuit breaker pole C closed
(status input from CB, 52-A = normally open)
PSL (IN)
CB STATUS
1030 CB Aux C (52-B)
Circuit breaker pole C open
(Status input from CB, 52-B = normally closed)
PSL (IN)
CB STATUS
1031 SPAR Enable
Enable internal single pole autorecloser.
Set with Opto input (if linked by PSL) is energized (> 1s).
At 1: 1P AR internal is enabled in the AR logic
At 0: AR 1P internal is disabled (even if set in MiCOM
S1 Agile). AR logic becomes 3P only with AR 3P cycle -
if TPAR =1
PSL (IN)
Autorecloser
1032 TPAR Enable
Enable internal three pole autorecloser
Set with Opto input (if linked by PSL) is energized (> 1s).
At 1: 3P AR internal is enabled in the AR logic
At 0: AR 3P internal is disabled (even if set in MiCOM
S1 Agile). 1P cycle available if SPAR =1
PSL (IN)
Autorecloser
1033 A/R Internal
Give internal autorecloser present (visible): If it is
assigned to an opto input in the PSL and energised, the
DDB:'A/R Internal' will enable the internal AR logic. This
opto input could be connected to an external condition
such as the Watchdog of the Main1 protection – this
activates the internal AR of Main 2 (P44x) in the case of
an internal failure of the Main1.
PSL (IN)
Autorecloser
1034 I A/R 1p In Prog
One-pole external autoreclose cycle in progress: If it is
assigned to an opto input in the PSL and energised, The
DDB:'A/R 1P in Prog' will block the internal DEF
protection as it indicates that an external single-pole
autoreclose cycle is in progress.
PSL (IN)
Autorecloser
