GE P50 Agile P253 - 2.4.12 IO Configuration Menu

5 Configuration
P50 Agile P253
5-78
P253/EN M/C
2.4.13 I/O Configuration Menu
2.4.14 View / Edit Settings
LED G : 8765
Gen Strt 0000
LED R : 8765
Gen Strt 0000
AND Logic : DCBA
Gen Strt 0000
Opto I/P : 654321
Rem. Rst. 000000
6 5
Relay : 654321
Gen Strt 000000
6 5 6 5 6 5
4
6
IO CONFIGURATION
SET For Save
CLEAR For Cancel
4
SAVE Settings
SET
CLEAR
DISCARD Settings
EDIT
(*)
(*)
(*)
(*)
(*)
(*)
Note: (*) indicates EDIT key is used to modify settings. Refer to the View and Edit settings section.
