GE P50 Agile P253 User Manual

P50 Agile P253
9 SCADA Communications
P253/EN M/C
9-9
Sr.No.
Function
Code
Register
No. of
Regs.
Format
Reg.
Type
Address Map
6
Parameters
04
IL1
2
32-bit Float
R
33281– 33282
IL2 2 32-bit Float R 33283– 33284
IL3 2 32-bit Float R 33285 – 33286
IN1 2 32-bit Float R 33287 – 33288
IN2
2
32-bit Float
R
33289 – 33290
I2
2
32-bit Float
R
33291 – 33292
I1 2 32-bit Float R 33293 – 33294
Thermal State 2 32-bit Float R 33295 – 33296
L1-RMS 2 32-bit Float R 33299 – 33300
L2-RMS 2 32-bit Float R 33301– 33302
L3-RMS
2
32-bit Float
R
33303– 33304
TC
2
32-bit Float
R
33305– 33306
BOC 2 32-bit Float R 33307– 33308
BOT 2 32-bit Float R 33309– 33310
I0 2 32-bit Float R 33311– 33312
Load Current 2 32-bit Float R 35201– 35202
Time To Th
Trip
2 32-bit Float R 35203– 35204
Nb of Th Trip 2 32-bit Float R 35205– 35206
Last Start
Time
2 32-bit Float R 35207– 35208
Last St
Current
2 32-bit Float R 35209– 35210
Nb Hot St
Allow
2 32-bit Float R 35211– 35212
Nb Cold St
Allow
2 32-bit Float R 35213– 35214
Time To Next St
2 32-bit Float R 35215- 35216
Total Nb of
Strt
2 32-bit Float R 35217- 35218
Nb
Emergency
Rst
2 32-bit Float R 35219- 35220
Motor Run Time
2
32-bit Float
R
35221- 35222
2.2 IEC-870-5-103
2.2.1 Overview
The specification IEC 60870-5-103 (Telecontrol Equipment and Systems Part 5 Section 103:
Transmission Protocols), defines the use of standards IEC 60870-5-1 to IEC 60870-5-5, which are
designed for communication with protection equipment.
