I>lift 2H
10.00 A
Editable setting
By using the (+ /5) or (- /6) key, the desired I>lift 2H setting can be
done. The setting range is 4 In to 32 In in steps of 0.01 In.
2.3.16.3 Group 1 – Overcurrent Submenu
2.3.16.3.1
Edit Settings
(if I>1Function, I>2Function and I>3 Function are disabled)
GROUP 1
Password protected window for “GROUP 1’’ setting:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, EARTH
FAULT 1, EARTH FAULT 2, THERMAL OVERLOAD, LOSS OF LOAD,
CB FAIL, STALL DETECTION and LIMITS NB STARTS.
Note: Group 1 setting will be seen only when it is enabled in
Configuration setting.
Password protected window for Overcurrent i.e. I>1 Function, I>2
Function and I>3 Function setting to Disabled / DT/ IEC S Inverse/ S
Inverse (1.3Sec)/ IEC V Inverse/ IEC E Inverse/ UK LT Inverse /IEEE M
Inverse/ IEEE V Inverse/ IEEE E Inverse /US Inverse /US ST Inverse
I>1Function
Disabled
Editable setting
By using the (+ /5) or (- /6) key, I>1Function is Disabled
I>2Function
Disabled
Editable setting
By using the (+ /5) or (- /6) key, I>2Function is Disabled
I>3Function
Disabled
Editable setting
By using the (+ /5) or (- /6) key, I>3Function is Disabled
2.3.16.3.2
Edit Settings
(if I>1 Function is selected for IEC curve)
GROUP 1
Password protected window for “GROUP 1’’ setting :
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, EARTH
FAULT 1, EARTH FAULT 2, THERMAL OVERLOAD, LOSS OF LOAD,
CB FAIL, STALL DETECTION and LIMITS NB STARTS
Note: Group 1 setting will be seen only when it is enabled in
Configuration setting.
OVERCURRENT
Password protected window for Overcurrent i.e. I>1 Function, I>2
Function and I>3 Function setting to Disabled / DT/ IEC S Inverse/ S
Inverse (1.3Sec)/ IEC V Inverse/ IEC E Inverse/ UK LT Inverse /IEEE M
Inverse/ IEEE V Inverse/ IEEE E Inverse /US Inverse /US ST Inverse
I>1 Function
IEC S Inverse
By using the (+ /5) or (- /6) key, I>1Function is set as IEC S Inverse.
