The output contact assigned to ‘Relay OK’ signal remains in active state when the relay is Healthy, i.e.
NO contact will be in closed position and vice versa.
The output contact assigned to ‘Relay OK’ will become inactive in case any error is detected/failure of
auxiliary supply.
There are 6 nos. of programmable binary outputs (changeover type contacts) marked as RL1 to RL6.
Any binary output can be assign as watchdog contact by assigning ‘Relay OK’
signal through
‘IO CONFIGURATION’ setting or using ‘IO Mask’ function in P50 Agile Configurator.
