GE P50 Agile P253 User Manual

P50 Agile P253
9 SCADA Communications
P253/EN M/C
9-15
Sr. No. INF Description
6 Semantics of Actual Channel: Used for DR Transmission
ACC
Description
1
IL1 - Primary
2 IL2
3 IL3
4 IN2 (Derived)
74 IN1 (Measured)
Sr. No. INF Description GI TYP COT FUN
7 Semantics of INFORMATION NUMBER: System Functions in control direction
0
Initialization of
general
interrogation
7 9 255
0
Time
synchronization
- 6 8 255
Sr. No.
INF
Description
GI
TYP
COT
FUN
8
Semantics of INFORMATION NUMBER: General commands in control direction
19 LED Reset ON 20 20 160
123 Trip ON/OFF 20 20 127
125 Close ON/OFF 20 20 127
94 Output 1 ON/OFF 20 20 127
95
Output 2
ON/OFF
20
20
127
96
Output 3
ON/OFF
20
20
127
97 Output 4 ON/OFF 20 20 127
98 Output 5 ON/OFF 20 20 127
99 Output 6 ON/OFF 20 20 127
2.3 DNP3.0
2.3.1 Overview
This section describes the specific implementation of the Distributed Network Protocol (DNP 3.0) in
P253 – Motor protection relay.
It uses Triangle MicroWorks, Inc. DNP 3.0 Slave Source Code Library Version 3.17.
For information on how to communicate with P253 using DNP3.0 protocol, this document should be
read in conjunction with the DNP3.0 Basic 4 document set and the DNP Subset Definitions document.
This implementation of DNP3.0 is fully compliant with DNP3.0 Subset Definition Level 2 and contains
many Subset Level 3 features including some functionality beyond Subset Level 3.
2.3.2 DNP V3.00 Device Profile
The following table provides a “Device Profile Document” in the standard format defined in the
DNP 3.0 Subset Definition Document. While it is referred to in the DNP3.0 Subset Definition as a
“Document”, it is only a component of a total interoperability guide.
