GE P50 Agile P253 User Manual

9 SCADA Communications
P50 Agile P253
9-24
P253/EN M/C
23 Start IN1>3 0 1
24 Start IN2>1 0 1
25
Start IN2>2
0
1
26
Start IN2>3
0
1
27 Th Alarm 0 1
28 Start I< 0 1
29 Start CB Fail 0 1
30 I> Blk by CBF 0 1
31
IN1> Blk by CBF
0
1
32
StrtDFail
0
1
33 CB Close Fail 0 1
34 CB Open Fail 0 1
35 Relay OK 0 1
36 Emergency Restart 0 1
37
Start Stall
0
1
38
Suprvsn T
0
1
39 Inhibit Start 0 1
40 Time between start 0 1
41 General Trip 0 1
42 Trip L1 0 1
43
Trip L2
0
1
44 Trip L3 0 1
45 Trip I>1 0 1
46 Trip I>2 0 1
47 Trip I>3 0 1
48
Trip I2>1
0
1
49
Trip I2>2
0
1
50 Trip I2>3 0 1
51 Trip IN1>1 0 1
52 Trip IN1>2 0 1
53 Trip IN1>3 0 1
54
Trip IN2>1
0
1
55
Trip IN2>2
0
1
56 Trip IN2>3 0 1
57 Th Trip 0 1
58 Thermal Lockout 0 1
59 Trip I< 0 1
60
Trip CB Fail
0
1
61
Trip Prolong
0
1
62 Trip Start 0 1
63 Rotor Lockout 0 1
64 Motor Start 0 1
65 Motor Run 0 1
66
External Trip
0
1
