2.3.4.4 Analog Inputs
The following table lists Analog Inputs (Object 30). Every Analog Inputs points are included in class 0
polls because they are included in one of classes 1, 2 or 3.
Analog Inputs
Static (Steady-State) Object Number: 30
Change Event Object Number: 32
Request Function Codes supported: 1 (read)
Static Variation reported when variation 0 requested: 1 (32-Bit Analog Input)
Change Event Variation reported when variation 0 requested: 1 (32-Bit Analog Change Event w/o
Time)
Change Event Scan Rate: The scan rate for analog input change events is fixed at 1s
Point
Index
Name/Description Initial value Initial Change
Event Class (1, 2, 3 or
none)
0 IN1 0 3
1
IL 1
0
3
2
IL 2
0
3
3 IL 3 0 3
4 IN2 0 3
5 I0 0 3
6 I1 0 3
7
I2
0
3
8
L1-RMS
0
3
9 L2-RMS 0 3
10 L3-RMS 0 3
11 Th State 0 3
12 Load Current 0 3
13
Last I start
0
3
14
BOT
0
3
15 Last Start time 0 3
16 Time to Thermal trip 0 3
17 Time to Next Start 0 3
18 Motor Run Time 0 3
