Note: The functions that can be assigned to relay, LED G, LED R and AND Logic are listed in
Chapter 8: Monitoring and Control.
2.3.13 O/P Relay Configuration Menu
2.3.13.1 View / Edit Settings
O/P RELAY CONFIG
Password protected window for “O/P RELAY CONFIGURATION’’
settings: Contact HR/SR, O/P-1 Open Time, O/P-2 Open Time, O/P-3
Open Time, O/P-4 Open Time, O/P-5 Open Time and O/P-6 Open Time,
LED G HR/SR, LED R HR/SR, ANDEQ A Op Time, ANDEQ Rst Time,
ANDEQ B Op Time, ANDEQ B Rst Time, ANDEQ C Op Time, ANDEQ C
Rst Time, ANDEQ D Op Time and ANDEQ D Rst Time.
Contact HR/SR
000000
Editable setting
By using the (+ /5) or (- /6) key, the desired Contact HR/SR can be
set as ‘1’=HR / ‘0’=SR.
O/P–1 Open Time
0.05 S
Editable setting
By using the (+ /5) or (- /6) key, the desired O/P–1 Open Time can be
set. The setting range is from 0 to 1s in steps of 0.01s
By using the (+ /5) or (- /6) key, the desired O/P–2 Open Time can be
set. The setting range is from 0 to 1s in steps of 0.01s
O/P–3 Open Time
0.05 S
Editable setting
By using the (+ /5) or (- /6) key, the desired O/P–3 Open Time can be
set. The setting range is from 0 to 1s in steps of 0.01s
O/P–4 Open Time
0.05 S
Editable setting
By using the (+ /5) or (- /6) key, the desired O/P–4 Open Time can be
set. The setting range is from 0 to 1s in steps of 0.01s
By using the (+ /5) or (- /6) key, the desired O/P–5 Open Time can be
set. The setting range is from 0 to 1s in steps of 0.01s
O/P–6 Open Time
0.05 S
Editable setting
By using the Plus / Up arrow key (+ /5) or the Minus / Down arrow key
(- /6) key, the desired O/P–6 Open Time can be set. The setting range
is from 0 to 1s in steps of 0.01s
LED G HR/SR
0000
Editable setting
By using the (+ /5) or (- /6) key, the desired function for LED GREEN
can be set as HR/SR (‘1’=HR /’0’=SR)
