P50 Agile P253
5 Configuration
P253/EN M/C
5-47
IN1>1 Reset Char
DT
Read-only
The IN1>1 Reset Char Function is fixed i.e. DT (Definite Time).
IN1>1 tRESET
0.01 S
Editable setting
By using the (+ /5) or (- /6) key, the desired IN1>1 tRESET can be
set. The setting range is from 0 to 100s in steps of 0.01s.
IN1>1 2HBlocking
Disabled
Editable setting
By using the (+ /5) or (- /6) key, IN1>1 2HBlocking function can be
Enabled / Disabled.
Note: The settings of IN1>2 Function and IN1>3 Function to be done in similar manner as that of
IN1>1 Function.
2.3.16.6 Group 1 – Earth Fault 2 Submenu
2.3.16.6.1
Edit Settings
(if IN2>1 Function, IN2>2 Function and IN2>3 Function are disabled)
GROUP 1
Password protected window for
“GROUP 1’’
settings:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, EARTH
FAULT 1, EARTH FAULT 2, THERMAL OVERLOAD, LOSS OF LOAD,
CB FAIL, STALL DETECTION and LIMITS NB STARTS.
EARTH FAULT 2
Password protected window for Earth Fault 2 i.e. IN2>1 Function,
IN2>2 Function and IN2>3 Function which can be set as Disabled / DT /
IEC S Inverse/ S Inverse (1.3Sec)/ IEC V Inverse/ IEC E Inverse/ UK LT
Inverse /IEEE M Inverse/ IEEE V Inverse/ IEEE E Inverse /US Inverse
/US ST Inverse.
IN2>1 Function
Disabled
Editable setting
By using the (+ /5) or (- /6) key, IN2>1 Function is set as Disabled.
IN2>2 Function
Disabled
Editable setting
By using the (+ /5) or (- /6) key, IN2>2 Function is set as Disabled.
IN2>3 Function
Disabled
Editable
s
etting
By using the (+ /5) or (- /6) key, IN2>3 Function is set as Disabled.
