GE PFSS5NJWSS

30
How to access the evaporator (cont.)
7. Remove the two ¼-in. hex-head screws that attach the icemaker to the
freezer wall.
8. Using a small flat-blade screwdriver, expand the 2 clips and disconnect the
icemaker wire harness.
mabe CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. January 2008
