31
How to access the evaporator (cont.)
9. Remove the two ¼-in. hex-head screws that attach the icemaker bin support
to the left freezer wall.
mabe CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. January 2008
Note: The freezer fan cover is held to the evaporator cover with a Phillips-head screw, 3
cover tabs, and 2 right side hinge tabs.
10. Remove the single Phillips-head screw
.
