Vent Grille
Cleaning Cream
Scrub Sponge
Sheet Metal Screws (9)
(8-18 x 3/8")
Foam Gasket Tape
Vent Grille Gasket
16
Burner Grate (2)
Regulator
Blower Assembly and (4)
Mounting Nuts (10-32 keps – nuts
with lock washers attached)
Blower Plenum
Vent Filter
• Blower assembly
• Blower plenum
• (4) Nuts (10-32 keps – nuts with
lock washers attached)
• (9) Sheet metal screws
(8-18 x 3/8")
• Foam gasket tape (9-ft roll)
• Vent grille
• Vent filter
• Vent grille gasket
• Cleaning cream
• Scrub sponge or scraper
(on some models)
• Burner grates
• Burner heads
(1 small (A), 2 medium (B),
1 large (C))
• Burner caps
(1 small, 2 medium, 1 large)
• Gas pressure regulator &
LP Conversion Instructions
• Attached 120-volt grounded
plug cord
• Reflective tape
Burner Caps and Burner Heads
Burner Cap and Burner Head
Burner Cap and Burner Head
Reflective Tape
CAUTION:
DO NOT LIFT
FROM VENT
OPENING OR
BUMP GLASS
Check to be sure that all packing materials
and tape have been removed This will include
tape on control knobs (if applicable), adhesive
tape, wire ties, cardboard and protective
plastic Failure to remove these materials could
result in damage to the appliance once the
appliance has been turned on and surfaces
have heated
