The countertop must have a deep flat surface
to accommodate the cooktop and the vent
Countertops with a rolled front edge and
backsplash may not provide the flat surface
area required
Clearance between inside front of cabinet and
rear of countertop cutout must be 20
5
⁄8
”
in order to
accommodate cooktop depth
A 1/2
”
wide flat area is required around the edge
of opening for support of the unit The cooktop
unit must be level and sit squarely into countertop
opening
Carefully cut countertop opening according to the
dimensions shown in the illustration Be sure that
opening is cut squarely, with sides parallel to each
other and rear exactly perpendicular to sides
Cut hole in cabinet wall or floor as appropriate for your
installation Make sure exhaust duct is located between wall
studs or floor joists
20
5
⁄8
”
1
7
⁄8
”
min
20
5
⁄8
”
1
7
⁄8
”
min
25
”
28
7
⁄8
”
9
1
⁄8
”
18
3
⁄4
”
10
1
⁄8
”
6
1
⁄8
”
Back Venting
(Requires 3
1
⁄4” x 10")
Rear Wall Venting
Downward Venting
3
In general, the use of flexible ducting is discouraged because
it can cause severely restricted airflow However, if the
blower outlet and the floor or wall duct location do NOT align
well, then flexible METAL ducting can be used to adapt to an
offset Good alignment without use of flexible ducting is best
• Do not exceed the maximum recommended offset of 6"
• Do not allow the flexible ducting to kink or collapse
• Do stretch the flexible ducting as much as possible to
eliminate as much of the corrugation as possible
4
5
2
3
⁄8
”
min
A 3
1
⁄4” x 10” rectangle to 6” round transition duct is available
at your local building supply store
Bottom Venting
6" Max
Centerline
to
Centerline
Offset
19
25” min flat surface area required
