GE Phasor XS - Scan Definition and Operation; Linear and Sector Scan Setup

12
12
Dening the Scan – LINEAR
The sequence in which the phased array probe’s elements re are
dened using features located in the SCAN menu.
For LINEAR scan types set the following:
SCAN TYPE – • ELECTRNC (choose linear)
WAVE TYPE – • ELECTRNC (shear or longitudinal)
ANGLE START – • SCAN PATT (constant ring angle for linear)
First Element – • APERATURE (element where it begins)
Number of Steps – • APERATURE (number of steps in scan)
APRERATURE SIZE – • (number of elements in the step)
APRERATURE STEP – • (number of elements stepped from one
step to the next in the linear scan)
CALC – • SCAN PATT (calculate delay laws)
