Viewing Measured Results
To determine which measured results are displayed, press to
access the DISPLAY menu
Set Readings in Each of the Four Small Boxes – • RESULTS1
Set Readings in the Large Box – • RESULTS2
CHOICES INCLUDE:
BEAM— Angular position of the Beam Cursor
P%A/B— Peak amp. of all beams in scan currently captured by
Gate A or B(as a % of FSH)
PSA/B— Soundpath distance of peak beams in scan currently
captured by Gate A or B
PPA/B— Projection distance of all beams in scan currently
captured by Gate A or B
