Guide to the Keypad
-- Mode Selector: Phased Array or Conventional Operating Modes•
• -- View Select: Frame and/or A-Scan
• -- Gain Increment/Decrement: Press and hold to change between
digital and analog gain
• -- ZOOM View: Expand the display to entire screen
Press again to return to normal view mode
• -- Home Key: Returns the instrument to the phased array
or conventional Home Menu. If held for 3 seconds, automatically
performs a focal law calculation
• -- Freeze Key: Freezes the displayed image(s). If held for 3 seconds,
automatically generates and stores a report
