GE Profile Performance ADVANTIUM SCA2000BAA - Door Switches

– 54 –
MOUNTING
SCREWS
PRIMARY
INTERLOCK
OVEN DR.
MONITOR
INTERLOCK
DOOR
SENSING
MONITOR
LEVER
DAMPER DOOR
SENSING SWITCH
SMART BOARD
CN11
CN1
RY2
CN6 CN4 CN2
DAMPER
DOOR
SENSING
SWITCH
OVEN DOOR MONITOR
INTERLOCK SWITCH (MIDDLE)
CN12
SWITCH SWITCH
DESCRIPTION CONTACTS
PRIMARY OPEN
DOOR MONITOR CLOSED
DOOR SENSING OPEN
OVEN DOOR OPEN POSITION
COOKING DAMPER SW. PLUNGER SWITCH
MODE POSITION POSITION CONTACTS
MICROWAVE OPEN NOT DEPRESSED CLOSED
SPEEDCOOK CLOSED DEPRESSED OPEN
DAMPER DOOR OPERATING MODES
24.5 Ω
(150˚C/1 Shot)
(302˚F/1 Shot)
DOOR SWITCHES
* Damper door sensing switch contacts are closed when
oven door is open
