– 21 –
Component Ohms Test Location Open Circuit Correction
Left Rear 1200W
Element*
46 Ω
RPSM J7-2 Orange/Black to K14 Orange Check Element and wiring.
Both OK - replace RPSM
Left Front 1000W
Inner Element*
56.2 Ω
RPSM J7-4 Yellow/Black to K10 Yellow Check Element and wiring.
Both OK - replace RPSM
Left Front 1200W
Outer Element*
46.2 Ω
RSPM J7-1 Yellow/Red to K10 Yellow Check Element and wiring.
Both OK - replace RPSM
Center 1050W
Inner Element**
51.5 Ω
DRM J2 to K7 Gray Check Element and wiring.
Both OK - replace DRM
Center 900W
Center Element**
61.3 Ω
DRM J6-2 Gray/White to K7 Gray Check Element and wiring.
Both OK - replace DRM
Center 1050W
Outer Element**
52.3 Ω
DRM J6-6 Violet to K7 Gray Check Element and wiring.
Both OK - replace DRM
Right Front 1100W
Inner Element*
51.3 Ω
RPSM J7-8 Blue/White to K7 Blue Check Element and wiring.
Both OK - replace RPSM
Right Front 1300W
Outer Element*
42.8 Ω
RPSM J2 to K7 Blue Check Element and wiring.
Both OK - replace RPSM
Right Rear 120W
Element*
0.5 Ω
RPSM J7-12 Brown to J7-3 Brown/White Check Element and wiring.
Both OK - replace RPSM
WARNING: The power must be disconnected from the cooktop.
The resistance of certain elements and the continuity of certain element circuit wiring can be tested without
removing the cooktop from its installation. This test will aid the service technician in determining if the RPSM
or the DRM should be replaced. This test assumes the touch board functions properly.
Model PP945
* Requires opening the drop box.
** Requires removing cooktop from it's installation and removing glass top.
Component Ohms Test Location Open Circuit Correction
Left Rear 1100W
Inner Element*
50 Ω
RPSM J2 to K7 Orange Check Element and wiring.
Both OK - replace RPSM
Left Rear 1300W
Outer Element*
43 Ω
RPSM J7-2 to K7 Orange Check Element and wiring.
Both OK - replace RPSM
Left Front 1200W
Element*
45 Ω
RPSM J7-12 to K10 Yellow Check Element and wiring.
Both OK - replace RPSM
Right Front 1050W
Inner Element**
52 Ω
RPSM J7-1 to DRM K7 Blue Check Element and wiring.
Both OK - replace DRM
Right Front 900W
Center Element**
61 Ω
RPSM J7-3 to DRM K7 Blue Check Element and wiring.
Both OK - replace DRM
Right Front 1050W
Outer Element**
53 Ω
RPSM J7-4 to DRM K7 Blue Check Element and wiring.
Both OK - replace DRM
Right Rear 1200W
Element*
46.5 Ω
RPSM J7-8 to K14 Brown Check Element and wiring.
Both OK - replace RPSM
Element Resistance Troubleshooting
Model PP975
