GE Profile PSB42LSRBV

– 25 –
DC CONNECTIONS AC CONNECTIONS
CON PIN DESCRIPTION WIRE COLOR CON PIN DESCRIPTION WIRE COLOR
CN2 1 Condenser Fan Feedback
Red
CN1
1 L1 (Switched thru Master Switch) Black
CN2 2 Condenser Fan VDC
Light Blue
CN1
2 Neutral (Switched thru Master Switch) Red
CN2 3 Condenser Fan Common Gray
CN2 4 3-Way Valve Red CN7 1 FZ Defrost (Switched L1) Brown
CN2 5 3-Way Valve Black CN7 2 FZ Defrost (Neutral) Orange
CN2 6 FZ Door Switch White/Yellow CN7 3 Icemaker (L1) Black
CN2 7 FZ & FF Door Switch (Common) Gray CN7 4 Icemaker (Water) (Switched L1) Blue
CN2 8 3-Way Valve Blue CN7 5 Icemaker (Neutral) Red
CN2 9 3-Way Valve Yellow CN7 6 Auger & Cube Motor (Switched Neutral) P/Blue
CN2 10 3-Way Valve Orange CN7 7 Cube Motor (Switched L1) Light Blue
CN2 11 Empty CN7 8 Auger Motor (Switched L1) Pink
CN2 12 External Thermistor Red CN7 9 FZ Light (L1) Black
CN2 13 FF Door Switch White/Blue CN7 10 FZ Light (Switched Neutral) White/Blue
CN2 14 Empty CN7 11 Empty
CN7 12 Empty
CN3 1 Duct Door Cam Switch #1 Blue
CN3 2 Duct Door Cam Switch #2 Purple CN8 1 Water Valve (Icemaker) (Switched L1) Purple
CN3 3 Dispenser Switch White CN8 2 Water Valve (Dispenser) (Switched L1) Gray
CN3 4 Dispenser Components (Common) Gray CN8 3 Water Valve (Neutral) (Icemaker & Dispenser) Red
CN3 5 Dispenser Light Light Blue CN8 4 Duct Door Motor & Dispenser Heater (Neutral) Red
CN3 6 Empty CN8 5 Dispenser Heater (Switched L1) Brown
CN8 6 Duct Door Motor (Switched L1) White
CN4 1 Temperature Control & Display Black CN8 7 Compressor (3 Phase) Black
CN4 2 Temperature Control & Display Brown CN8 8 Compressor (3 Phase) Purple
CN4 3 Temperature Control & Display Red CN8 9 Empty
CN4 4 Temperature Control & Display Orange CN8 10 FZ Door Switch (Auger & Cube Motor) P/Blue
CN4 5 Temperature Control & Display Yellow CN8 11 FF Door Light Switch (Switched Neutral) Yellow
CN4 6 Temperature Control & Display Pink CN8 12 FZ Door Light Switch (Switched Neutral) Orange
CN4 7 Temperature Control & Display Blue CN8 13 FF Door Light Switch (L1) Black
CN4 8 Temperature Control & Display Purple CN8 14 Compressor Overload (Pwr Supply Neutral) Light Blue
CN4 9 Temperature Control & Display Gray CN8 15 Compressor Overload (Pwr Supply Neutral) Light Blue
CN4 10 Temperature Control & Display White CN8 16 Compressor (3 Phase) Blue
CN4 11 Temperature Control & Display Light Blue
CN4 12 Temperature Control & Display White/Black CN9 1 FF Defrost (Switched L1) White
CN4 13 Temperature Control & Display White/Red CN9 2 FF Defrost (Neutral) Red
CN4 14 Temperature Control & Display White/Blue CN9 3 FF Lights (Switched L1) Light Blue
CN4 15 Temperature Control & Display White/Yellow CN9 4 FF Lights (Neutral) Red
CN4 16 Empty CN9 5 Empty
CN9 6 Empty
CN5 1 Empty CN9 7 Empty
CN5 2 FF Fan & Thermistors (Common) Gray CN9 8 Empty
CN5 3 FF Thermistor Yellow CN9 9 Empty
CN5 4 FF Evaporator Thermistor Pink
CN5 5 FF Fan Feedback Brown
CN5 6 FF Fan VDC Orange
CN6 1 FZ Fan Feedback Black
CN6 2 FZ Fan VDC Yellow
CN6 3
FZ Fan, Thermistors & Cube Switch
(Common)
Gray
CN6 4 Empty
Connector Description
