GE Profile WPDH8800J Technical Service Guide

– 55 –
Service Mode Test Sequence
t14 Spin Test Enter Displays “estimated” and “current” rpm. Unit begins spinning at 410 rpm
Start Ramps up to 1050 rpm
Start Ramps up to 1150 rpm
Start Ramps up to 1300 rpm
Power Ramps down and returns to service mode screen
t15 Dispenser
Test
Enter Displays “pre-wash” and dispenser moves to position 1
Start Displays “main detergent” and dispenser moves to position 2
Start Displays “bleach” and dispenser moves to position 4
Start Displays “fabric softener” and dispenser moves to position 3
Start Repeats above sequence, starting with “pre-wash”
Power Drains and returns to service mode screen
t16 Bulk Pumps
Test
Enter Displays “left detergent pump”; water fi lls and primes left detergent
Start Displays “softener pump” and begins priming
Start Displays “right det pump” and begins priming
Start Continues cycling through the bulk pumps
Power Drains and returns to service mode screen
t17 Bulk Sensors
Test
Enter Displays the status of Left Detergent, Softener and Right Detergent
Power Returns to service mode screen
t18 Auto Spin
Profi le
Enter Slowly ramps up to 90, then 120, then 410
Power Interrupts and returns to service mode screen
t19 Bulk Manual
Priming
Enter Displays “prime left detergent,” “prime softener,” prime right detergent”
with one highlighted
Enter Begins priming selected, with water on to rinse it from dispenser drawer
Power Drains; then returns to service mode screen
t20 Bulk Primed
Status
Enter Displays “left detergent pump,” “softener pump,” "right detergent pump”
with one highlighted
Enter Displays “left det primed status”; choose status “yes” (lines primed) or
“no” (lines not primed)
Enter Returns back to “Bulk Primed Status”
Power Returns to service mode screen
