19
Line Filter (cont.)
3.
Press the locking tab on each
terminal and remove the 2
ground wires.
4.
Remove the 2 (7-mm) hex-
head screws that hold the filter
to the frame.
5.
Move the filter to the right.
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FO
R PUBLIC DISCLOSUR
E. September
2008
18
20
Table of Contents
Important Safety Notice
2
Table of Contents
3
Component Locator Views
7
Front View
8
Circuit Board Connections
9
Inverter Board
10
Control Panel
13
Control Board
15
Line Filter
18
Door Lock
20
Front Panel
22
Dispenser Assembly
23
Dispenser Motor
26
Power Board Assembly
28
Water Level Control
30
Water Valve
34
Heater Assembly
36
Motor Assembly
40
Door Hinge
46
Service Test Mode
50
Pump
53
Diagnostic Tests
55
Error Codes
61
