Door Hinge
To remove the door hinge:
1. Remove the door. (See Door.)
2. Grasp the hinge pin with a pair of
pliers and pull the pin out of the hinge.
Remove the door hinge plate.
Note: It may be helpful to drive the hinge
pin upward using a punch.
3. Remove the 3 Phillips-head screws that
hold the door hinge to the front panel.
4. Remove the gasket from the front panel.
5. Push and fold the left side of the gasket
inside the wash basket.
