21
Remove the door lock
1. Open the door and remove the 3
Phillips-head screws that hold the door
lock to the front panel.
2. Use a long-nose pliers to grasp the
wire loop at the spring location and
expand it to clear the gasket.
3. Remove the spring and wire from the
gasket.
4. Pull the right side of the gasket away from
the front panel.
5. Pull the door lock to the opening and
remove the 3 wire harnesses.
Note: The door latch is solenoid-activated. It can remain
locked after power is removed.
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
