35
Pump
The pump consists of a 120-VAC, 60-Hz motor, impeller, impeller housing, and a
removable strainer that helps prevent foreign objects from entering the pump impeller
and drain outlet.
The pump runs whenever the washer is in the spin function of a cycle.
The pump runs if the water level control overflow switch is closed and the washer is
plugged in. (Overflow protection)
The pump is capable of eliminating 17 gallons (64 liters) per minute.
Recommended minimum standpipe diameter is 1 1/4 inches.
Standpipe maximum height is 96 inches, measured from the floor at the washer
location.
The pump motor has an approximate resistance value of 10.6 Ω.
Operation of the pump can be checked by using service test mode t08. (See Service
Test Mode.)
Specific failures associated with the pump can initiate error code E8. (See Service
Test Mode.)
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
