54
Service Test Mode (cont.)
Checks the control status of the prime status of the
pumps and allows the user to change/reset the
prime status.
t20 Bulk Primed Status
Manually initiates the priming of the Smart
Dispenser pumps.
t19 Bulk Manual Priming
Tests each spin speed of the washer. Note: No
out-of-balance detection will be performed here,
so the washer will spin up regardless of any out-of
balance condition in the drum.
t18 AutoSpin Profile
Verifies all the Smart Dispenser Sensors work.t17 Bulk Sensors Test
Verifies all the Smart Dispenser Pumps work.t16 Bulk Pumps Test
Verifies the dispenser motor works and can locate
all 4 dispenser positions.
t15 Dispenser Test
DescriptionTest Mode
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
