Condenser Fan Not Running
Always check for obstruction first.
Unplug refrigerator to reset
main control board.
Warm freezer thermistor to
70 ˚F and set temperature
controls to 5 and 5.
Reconnect power.
At the condenser fan connector,
check for 13 VDC from the red to
white/silver wire and 11 to 13 VDC
from the yellow to white/silver wire.
Is the voltage correct for both?
Replace the condenser
fan motor.
YES
Unplug J2 connector on the main control
board. Check for 13 VDC between pins
J2-3 and J2-8 and 11 to 13 VDC between
pins J2-3 and J2-5.
Is the voltage correct for both?
NO
Replace main
control board.
YES
NO
Repair wiring between
main control board and
condenser fan.
To Next Page
