7 4 7
* # " (
D Press key to toggle between small or large focal spot (0.1 or 0.3, respectively).
D The readout indicates the size of the selected focal spot in the language
programmed at installation.
Note: When magnification is selected, the system automatically selects the small focal
spot. When the standard exam is selected, the system automatically selects the
large focal spot.
If Stereotix 2 is installed, the large focal spot is automatically selected.
7 -72 7
/ ;, 86 6 7 -72+
D In AEC mode and manual mode, press to select the focal track.
D The readout indicates the type of focal track: molybdenum or rhodium.
Note: In AOP mode, selection is automatic (pressing the key has no effect).
- 7
/ ;, !# " <! =
D In AEC and manual mode, the key selects one of the three filters.
D The readout indicates the type of filter: Mo (molybdenum), Rh (rhodium) or Al
(aluminum).
Note: Some filter/focal track pairs are inhibited as a function of kV values. The program
automatically selects an authorized filter and displays the selection.
Note: In AOP mode, filter selection is automatic (pressing the key has no effect).
(The AOP mode does not select the AL filter).
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
