Installation
Installing stress- sh ields on the interrupting chambers
GE Information L31- 7510EN/02
2/4
03- 2017
Preparing th e stress- shields
Necessary
Grid Solutions
components
List of the Grid Solutions components necessary for the assembling (
per
pole
):
Mark Diagram Designation Number
(1) Stress- shields ring 2
(2) Bracket 8
(3)
Screws
H M10-30
8
Necessary product
MOBILPLEX 47 - MOBILUX EP3 : screw greasing.
Assembling
Install the brackets (2) on the stress- shields ring (1) using screws (3) do
not
tighten
.
x4
HM10-30
3
2
1
