Description and operation
General description of the circuit- b reaker
GE Information L12- 017EN/04
4/6
04- 2017
Operating d evice
Description
The operating device (11) is a spring operating mechanism of the FK3- 4 type.
The door of the operating device (11) is equipped with two windows. These
windows permit to display the optical signalization of the circuit- breaker state
and closing spring state.
Diagram
3
11
Fastening
The operating device is fastened on the housing (3).
