The DNP / IEC 60870-5-104 point lists always begin with point 0 and end at the first “Off” value. Since DNP /
IEC 60870-5-104 point lists must be in one continuous block, any points assigned after the first “Off” point
are ignored.
Changes to the DNP / IEC 60870-5-104 point lists will not take effect until the L60 is restarted.
g) IEC 61850 PROTOCOL
PATH: SETTINGS Ö PRODUCT SETUP ÖØ COMMUNICATIONS ÖØ IEC 61850 PROTOCOL
The L60 Line Phase Comparison System is provided with optional IEC 61850 communications capability.
This feature is specified as a software option at the time of ordering. Refer to the Ordering section of chap-
ter 2 for additional details. The IEC 61850 protocol features are not available if CPU type E is ordered.
The L60 supports the Manufacturing Message Specification (MMS) protocol as specified by IEC 61850. MMS is supported
over two protocol stacks: TCP/IP over ethernet and TP4/CLNP (OSI) over ethernet. The L60 operates as an IEC 61850
server. The Remote inputs and outputs section in this chapter describe the peer-to-peer GSSE/GOOSE message scheme.
The GSSE/GOOSE configuration main menu is divided into two areas: transmission and reception.
PATH: SETTINGS Ö PRODUCT SETUP ÖØ COMMUNICATIONS ÖØ IEC 61850 PROTOCOL Ö GSSE/GOOSE CONFIGURATION
The main transmission menu is shown below:
 IEC 61850 PROTOCOL

 GSSE / GOOSE
 CONFIGURATION
MESSAGE
 SERVER
 CONFIGURATION
MESSAGE
 IEC 61850 LOGICAL
 NODE NAME PREFIXES
MESSAGE
 MMXU DEADBANDS

MESSAGE
 GGIO1 STATUS
 CONFIGURATION
MESSAGE
 GGIO2 CONTROL
 CONFIGURATION
MESSAGE
 GGIO4 ANALOG
 CONFIGURATION
MESSAGE
 REPORT CONTROL
 CONFIGURATION
MESSAGE
 XCBR
 CONFIGURATION
MESSAGE
 XSWI
 CONFIGURATION
 GSSE / GOOSE
 CONFIGURATION
 TRANSMISSION

MESSAGE
 RECEPTION

NOTE
NOTE
