GE Multilin L60 Line Phase Comparison System 6-21
6 ACTUAL VALUES 6.4 RECORDS
6
6.4.5 BREAKER MAINTENANCE
PATH: ACTUAL VALUES ÖØ RECORDS ÖØ MAINTENANCE Ö BREAKER 1(2)
There is an identical menu for each of the breakers. The BKR 1 ARCING AMP values are in units of kA
2
-cycles. Refer to the
COMMANDS ÖØ CLEAR RECORDS menu for clearing breaker arcing current records. The BREAKER OPERATING TIME is
defined as the slowest operating time of breaker poles that were initiated to open.
BREAKER 1
BKR 1 ARCING AMP φA:
0.00 kA2-cyc
MESSAGE
BKR 1 ARCING AMP φB:
0.00 kA2-cyc
MESSAGE
BKR 1 ARCING AMP φC:
0.00 kA2-cyc
MESSAGE
BKR 1 OPERATING TIME
φA: 0 ms
MESSAGE
BKR 1 OPERATING TIME
φB: 0 ms
MESSAGE
BKR 1 OPERATING TIME
φC: 0 ms
MESSAGE
BKR 1 OPERATING
TIME: 0 ms
