6 ACTUAL VALUES 6.2 STATUS
6
There are 256 FlexState bits available. The second line value indicates the state of the given FlexState bit.
6.2.13 ETHERNET
PATH: ACTUAL VALUES Ö STATUS ÖØ ETHERNET
These values indicate the status of the primary and secondary Ethernet links.
6.2.14 DIRECT INPUTS
PATH: ACTUAL VALUES Ö STATUS ÖØ DIRECT INPUTS
The AVERAGE MSG RETURN TIME is the time taken for direct output messages to return to the sender in a direct input/output
ring configuration (this value is not applicable for non-ring configurations). This is a rolling average calculated for the last
ten messages. There are two return times for dual-channel communications modules.
The
UNRETURNED MSG COUNT values (one per communications channel) count the direct output messages that do not
make the trip around the communications ring. The
CRC FAIL COUNT values (one per communications channel) count the
direct output messages that have been received but fail the CRC check. High values for either of these counts may indicate
on a problem with wiring, the communication channel, or one or more relays. The
UNRETURNED MSG COUNT and CRC FAIL
COUNT
values can be cleared using the CLEAR DIRECT I/O COUNTERS command.
The
DIRECT INPUT 1 to DIRECT INPUT () values represent the state of each direct input.
 ETHERNET

ETHERNET PRI LINK
STATUS: OK
Range: Fail, OK
MESSAGE
ETHERNET SEC LINK
STATUS: OK
Range: Fail, OK
 DIRECT INPUTS

AVG MSG RETURN
TIME CH1: 0 ms
MESSAGE
UNRETURNED MSG
COUNT CH1: 0
MESSAGE
CRC FAIL COUNT
CH1: 0
MESSAGE
AVG MSG RETURN
TIME CH2: 0 ms
MESSAGE
UNRETURNED MSG
COUNT CH2: 0
MESSAGE
CRC FAIL COUNT
CH2: 0
MESSAGE
DIRECT INPUT 1:
On
MESSAGE
DIRECT INPUT 2:
On
↓
MESSAGE
DIRECT INPUT :
On
