5.2 PRODUCT SETUP 5 SETTINGS
5
The breaker configuration settings are shown below. Changes to these values will not take effect until the UR is restarted:
PATH: SETTINGS Ö PRODUCT SETUP ÖØ COMMUNICATIONS ÖØ IEC 61850 PROTOCOL ÖØ XCBR CONFIGURATION
The CLEAR XCBR1 OpCnt setting represents the breaker operating counter. As breakers operate by opening and closing, the
XCBR operating counter status attribute (OpCnt) increments with every operation. Frequent breaker operation may result
in very large OpCnt values over time. This setting allows the OpCnt to be reset to “0” for XCBR1.
The disconnect switch configuration settings are shown below. Changes to these values will not take effect until the UR is
restarted:
PATH: SETTINGS Ö PRODUCT SETUP ÖØ COMMUNICATIONS ÖØ IEC 61850 PROTOCOL ÖØ XSWI CONFIGURATION
The CLEAR XSWI1 OpCnt setting represents the disconnect switch operating counter. As disconnect switches operate by
opening and closing, the XSWI operating counter status attribute (OpCnt) increments with every operation. Frequent switch
operation may result in very large OpCnt values over time. This setting allows the OpCnt to be reset to “0” for XSWI1.
Since GSSE/GOOSE messages are multicast Ethernet by specification, they will not usually be forwarded by net-
work routers. However, GOOSE messages may be fowarded by routers if the router has been configured for VLAN
functionality.
 XCBR
 CONFIGURATION
XCBR1 ST.LOC OPERAND
Off
Range: FlexLogic™ operand
MESSAGE
XCBR2 ST.LOC OPERAND
Off
Range: FlexLogic™ operand
↓
MESSAGE
XCBR6 ST.LOC OPERAND
Off
Range: FlexLogic™ operand
MESSAGE
CLEAR XCBR1 OpCnt:
No
Range: No, Yes
MESSAGE
CLEAR XCBR2 OpCnt:
No
Range: No, Yes
↓
MESSAGE
CLEAR XCBR6 OpCnt:
No
Range: No, Yes
 XSWI
 CONFIGURATION
XSWI1 ST.LOC OPERAND
Off
Range: FlexLogic™ operand
MESSAGE
XSWI2 ST.LOC OPERAND
Off
Range: FlexLogic™ operand
↓
MESSAGE
XSWI24 ST.LOC OPERAND
Off
Range: FlexLogic™ operand
MESSAGE
CLEAR XSWI1 OpCnt:
No
Range: No, Yes
MESSAGE
CLEAR XSWI2 OpCnt:
No
Range: No, Yes
↓
MESSAGE
CLEAR XSWI24 OpCnt:
No
Range: No, Yes
NOTE
