GE Multilin L60 Line Phase Comparison System 2-5
2 PRODUCT DESCRIPTION 2.1 INTRODUCTION
2
Table 2–3: L60 ORDER CODES (HORIZONTAL UNITS)
L60 - * ** - * * * - F ** - H ** - L ** - N ** - S ** - U ** - W/X ** For Full Sized Horizontal Mount
BASE UNIT L60 | | | | | | | | | | | | Base Unit
CPU E | | | | | | | | | | | RS485 and RS485
G | | | | | | | | | | | RS485 and multi-mode ST 10Base-F
H | | | | | | | | | | | RS485 and multi-mode ST redundant 10Base-F
J | | | | | | | | | | | RS485 and multi-mode ST 100Base-FX
K | | | | | | | | | | | RS485 and multi-mode ST redundant 100Base-FX
L | | | | | | | | | | | RS485 and single mode SC 100Base-FX
M | | | | | | | | | | | RS485 and single mode SC redundant 100Base-FX
N | | | | | | | | | | | RS485 and 10/100Base-T
P | | | | | | | | | | | RS485 and single mode ST 100Base-FX
R | | | | | | | | | | | RS485 and single mode ST redundant 100Base-FX
S | | | | | | | | | | | RS485 and six-port managed Ethernet communications
SOFTWARE 00 | | | | | | | | | | No software options
03 | | | | | | | | | | IEC 61850; not available for Type E CPUs
MOUNT/COATING H | | | | | | | | | Horizontal (19” rack)
A | | | | | | | | | Horizontal (19” rack) with harsh environmental coating
FACEPLATE/ DISPLAY C | | | | | | | | English display
D | | | | | | | | French display
R | | | | | | | | Russian display
A | | | | | | | | Chinese display
P | | | | | | | | English display with 4 small and 12 large programmable pushbuttons
G | | | | | | | | French display with 4 small and 12 large programmable pushbuttons
S | | | | | | | | Russian display with 4 small and 12 large programmable pushbuttons
B | | | | | | | | Chinese display with 4 small and 12 large programmable pushbuttons
K | | | | | | | | Enhanced front panel with English display
M | | | | | | | | Enhanced front panel with French display
Q | | | | | | | | Enhanced front panel with Russian display
U | | | | | | | | Enhanced front panel with Chinese display
L | | | | | | | | Enhanced front panel with English display and user-programmable pushbuttons
N | | | | | | | | Enhanced front panel with French display and user-programmable pushbuttons
T | | | | | | | | Enhanced front panel with Russian display and user-programmable pushbuttons
V | | | | | | | | Enhanced front panel with Chinese display and user-programmable pushbuttons
POWER SUPPLY
(redundant supply must
be same type as main supply)
H | | | | | | | 125 / 250 V AC/DC power supply
H | | | | | | RH 125 / 250 V AC/DC with redundant 125 / 250 V AC/DC power supply
L | | | | | | | 24 to 48 V (DC only) power supply
L | | | | | | RL 24 to 48 V (DC only) with redundant 24 to 48 V DC power supply
CT/VT MODULES 8P | 8F | | | | 4CT, 2 communications channels, standard 4CT/4VT (breaker-and-a-half)
DIGITAL INPUTS/OUTPUTS XX XX XX XX XX No Module
4A 4A 4A 4A | 4 Solid-State (no monitoring) MOSFET outputs
4B 4B 4B 4B | 4 Solid-State (voltage with optional current) MOSFET outputs
4C 4C 4C 4C | 4 Solid-State (current with optional voltage) MOSFET outputs
4D 4D 4D 4D | 16 digital inputs with Auto-Burnishing
4L 4L 4L 4L | 14 Form-A (no monitoring) Latching outputs
67 67 67 67 | 8 Form-A (no monitoring) outputs
6A 6A 6A 6A | 2 Form-A (voltage with optional current) and 2 Form-C outputs, 8 digital inputs
6B 6B 6B 6B | 2 Form-A (voltage with optional current) and 4 Form-C outputs, 4 digital inputs
6C 6C 6C 6C | 8 Form-C outputs
6D 6D 6D 6D | 16 digital inputs
6E 6E 6E 6E | 4 Form-C outputs, 8 digital inputs
6F 6F 6F 6F | 8 Fast Form-C outputs
6G 6G 6G 6G | 4 Form-A (voltage with optional current) outputs, 8 digital inputs
6H 6H 6H 6H | 6 Form-A (voltage with optional current) outputs, 4 digital inputs
6K 6K 6K 6K | 4 Form-C and 4 Fast Form-C outputs
6L 6L 6L 6L | 2 Form-A (current with optional voltage) and 2 Form-C outputs, 8 digital inputs
6M 6M 6M 6M | 2 Form-A (current with optional voltage) and 4 Form-C outputs, 4 digital inputs
6N 6N 6N 6N | 4 Form-A (current with optional voltage) outputs, 8 digital inputs
6P 6P 6P 6P | 6 Form-A (current with optional voltage) outputs, 4 digital inputs
6R 6R 6R 6R | 2 Form-A (no monitoring) and 2 Form-C outputs, 8 digital inputs
6S 6S 6S 6S | 2 Form-A (no monitoring) and 4 Form-C outputs, 4 digital inputs
6T 6T 6T 6T | 4 Form-A (no monitoring) outputs, 8 digital inputs
6U 6U 6U 6U | 6 Form-A (no monitoring) outputs, 4 digital inputs
6V 6V 6V 6V | 2 Form-A outputs, 1 Form-C output, 2 Form-A (no monitoring) latching outputs, 8 digital inputs
TRANSDUCER
INPUTS/OUTPUTS
(select a maximum of 3 per unit)
5A 5A 5A 5A | 4 dcmA inputs, 4 dcmA outputs (only one 5A module is allowed)
5C 5C 5C 5C | 8 RTD inputs
5D 5D 5D 5D | 4 RTD inputs, 4 dcmA outputs (only one 5D module is allowed)
5E 5E 5E 5E | 4 RTD inputs, 4 dcmA inputs
5F 5F 5F 5F | 8 dcmA inputs
INTER-RELAY
COMMUNICATIONS
(select a maximum of 1 per unit)
2A 2A C37.94SM, 1300nm single-mode, ELED, 1 channel single-mode
2B 2B C37.94SM, 1300nm single-mode, ELED, 2 channel single-mode
2E 2E Bi-phase, single channel
2F 2F Bi-phase, dual channel
2G 2G IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 1 Channel
2H 2H IEEE C37.94, 820 nm, 128 kbps, multimode, LED, 2 Channels
| 2S Six-port managed Ethernet switch with high voltage supply (110 to 250 V DC / 100 to 240 V AC)
| 2T Six-port managed Ethernet switch with low voltage power supply (48 V DC)
72 72 1550 nm, single-mode, LASER, 1 Channel
73 73 1550 nm, single-mode, LASER, 2 Channel
74 74 Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, LASER
75 75 Channel 1 - G.703; Channel 2 - 1550 nm, Single-mode LASER
76 76 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 1 Channel
77 77 IEEE C37.94, 820 nm, 64 kbps, multimode, LED, 2 Channels
7A 7A 820 nm, multi-mode, LED, 1 Channel
7B 7B 1300 nm, multi-mode, LED, 1 Channel
7C 7C 1300 nm, single-mode, ELED, 1 Channel
7D 7D 1300 nm, single-mode, LASER, 1 Channel
7E 7E Channel 1 - G.703; Channel 2 - 820 nm, multi-mode
7F 7F Channel 1 - G.703; Channel 2 - 1300 nm, multi-mode
7G 7G Channel 1 - G.703; Channel 2 - 1300 nm, single-mode ELED
7H 7H 820 nm, multi-mode, LED, 2 Channels
7I 7I 1300 nm, multi-mode, LED, 2 Channels
7J 7J 1300 nm, single-mode, ELED, 2 Channels
7K 7K 1300 nm, single-mode, LASER, 2 Channels
7L 7L Channel 1 - RS422; Channel 2 - 820 nm, multi-mode, LED
7M 7M Channel 1 - RS422; Channel 2 - 1300 nm, multi-mode, LED
7N 7N Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, ELED
7P 7P Channel 1 - RS422; Channel 2 - 1300 nm, single-mode, LASER
7Q 7Q Channel 1 - G.703; Channel 2 - 1300 nm, single-mode LASER
7R 7R G.703, 1 Channel
7S 7S G.703, 2 Channels
7T 7T RS422, 1 Channel
7W 7W RS422, 2 Channels
