B2A1 IEC 61850 Report Control 1 OptFlds 0 to 65535 --- 1 F001 0
B2A2 IEC 61850 Report Control 1 BufTm 0 to 4294967295 --- 1 F003 0
B2A4 IEC 61850 Report Control 1 TrgOps 0 to 65535 --- 1 F001 0
B2A5 IEC 61850 Report Control 1 IntgPd 0 to 4294967295 --- 1 F003 0
B2A7 ...Repeated for Report 2
B2CE ...Repeated for Report 3
B2F5 ...Repeated for Report 4
B31C ...Repeated for Report 5
B343 ...Repeated for Report 6
B36A ...Repeated for Report 7
B391 ...Repeated for Report 8
B3B8 ...Repeated for Report 9
B3DF ...Repeated for Report 10
B406 ...Repeated for Report 11
B42D ...Repeated for Report 12
B454 ...Repeated for Report 13
B47B ...Repeated for Report 14
B4A2 ...Repeated for Report 15
B4C9 ...Repeated for Report 16
IEC 61850 GGIO1 Configuration Settings (Read/Write Setting)
B500 Number of Status Indications in GGIO1 8 to 128 --- 8 F001 8
B501 IEC 61850 GGIO1 Indication operands (128 items) --- --- 1 F300 0
IEC 61850 Configurable GOOSE Transmission (Read/Write Setting) (8 modules)
B5A0 IEC 61850 Configurable GOOSE Function 0 to 1 --- 1 F102 0 (None)
B5A1 IEC 61850 Configurable GOOSE ID --- --- --- F209 “GOOSEOut_x_”
B5C2 Configurable GOOSE Destination MAC Address --- --- --- F072 0
B5C5 IEC 61850 Configurable GOOSE VLAN Transmit Priority 0 to 7 --- 1 F001 4
B5C6 IEC 61850 Configurable GOOSE VLAN ID 0 to 4095 --- 1 F001 0
B5C7 IEC 61850 Configurable GOOSE ETYPE APPID 0 to 16383 --- 1 F001 0
B5C8 IEC 61850 Configurable GOOSE ConfRev 1 to 4294967295 --- 1 F003 1
B5CA Configurable GOOSE Dataset Items for Transmission 0 to 256 --- 1 F232 0 (None)
B60A ...Repeated for Module 2
B674 ...Repeated for Module 3
B6DE ...Repeated for Module 4
B748 ...Repeated for Module 5
B7B2 ...Repeated for Module 6
B81C ...Repeated for Module 7
B886 ...Repeated for Module 8
IEC 61850 Configurable GOOSE Reception (Read/Write Setting) (8 modules)
B900 Configurable GOOSE Dataset Items for Transmission 0 to 128 --- 1 F233 0 (None)
B940 ...Repeated for Module 2
B980 ...Repeated for Module 3
B9C0 ...Repeated for Module 4
BA00 ...Repeated for Module 5
BA40 ...Repeated for Module 6
BA80 ...Repeated for Module 7
BAC0 ...Repeated for Module 8
Contact Inputs (Read/Write Setting) (96 modules)
BB00 Contact Input 1 Name --- --- --- F205 “Cont Ip 1“
BB06 Contact Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
BB07 Contact Input 1 Debounce Time 0 to 16 ms 0.5 F001 20
BB08 ...Repeated for Contact Input 2
BB10 ...Repeated for Contact Input 3
BB18 ...Repeated for Contact Input 4
Table B–9: MODBUS MEMORY MAP (Sheet 43 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
