GE UR series

B-58 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
C68C ...Repeated for Contact Output 50
C698 ...Repeated for Contact Output 51
C6A4 ...Repeated for Contact Output 52
C6B0 ...Repeated for Contact Output 53
C6BC ...Repeated for Contact Output 54
C6C8 ...Repeated for Contact Output 55
C6D4 ...Repeated for Contact Output 56
C6E0 ...Repeated for Contact Output 57
C6EC ...Repeated for Contact Output 58
C6F8 ...Repeated for Contact Output 59
C704 ...Repeated for Contact Output 60
C710 ...Repeated for Contact Output 61
C71C ...Repeated for Contact Output 62
C728 ...Repeated for Contact Output 63
C734 ...Repeated for Contact Output 64
Reset (Read/Write Setting)
C750 FlexLogic™ operand which initiates a reset 0 to 65535 --- 1 F300 0
Control Pushbuttons (Read/Write Setting) (7 modules)
C760 Control Pushbutton 1 Function 0 to 1 --- 1 F102 0 (Disabled)
C761 Control Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
C762 ...Repeated for Control Pushbutton 2
C764 ...Repeated for Control Pushbutton 3
C766 ...Repeated for Control Pushbutton 4
C768 ...Repeated for Control Pushbutton 5
C76A ...Repeated for Control Pushbutton 6
C76C ...Repeated for Control Pushbutton 7
Clear Records (Read/Write Setting)
C770 Clear Fault Reports operand 0 to 65535 --- 1 F300 0
C772 Clear Event Records operand 0 to 65535 --- 1 F300 0
C773 Clear Oscillography operand 0 to 65535 --- 1 F300 0
C774 Clear Data Logger operand 0 to 65535 --- 1 F300 0
C775 Clear Breaker 1 Arcing Current operand 0 to 65535 --- 1 F300 0
C776 Clear Breaker 2 Arcing Current operand 0 to 65535 --- 1 F300 0
C77C Clear Channel Status operand 0 to 65535 --- 1 F300 0
C77D Clear Energy operand 0 to 65535 --- 1 F300 0
C77F Clear Unauthorized Access operand 0 to 65535 --- 1 F300 0
C782 Reserved (13 items) --- --- --- F001 0
Force Contact Inputs/Outputs (Read/Write Settings)
C7A0 Force Contact Input x State (96 items) 0 to 2 --- 1 F144 0 (Disabled)
C800 Force Contact Output x State (64 items) 0 to 3 --- 1 F131 0 (Disabled)
Direct Inputs/Outputs (Read/Write Setting)
C880 Direct Device ID 1 to 16 --- 1 F001 1
C881 Direct I/O Channel 1 Ring Configuration Function 0 to 1 --- 1 F126 0 (No)
C882 Platform Direct I/O Data Rate 64 to 128 kbps 64 F001 64
C883 Direct I/O Channel 2 Ring Configuration Function 0 to 1 --- 1 F126 0 (No)
C884 Platform Direct I/O Crossover Function 0 to 1 --- 1 F102 0 (Disabled)
Direct input/output commands (Read/Write Command)
C888 Direct input/output clear counters command 0 to 1 --- 1 F126 0 (No)
Direct inputs (Read/Write Setting) (96 modules)
C890 Direct Input 1 Device Number 0 to 16 --- 1 F001 0
C891 Direct Input 1 Number 0 to 96 --- 1 F001 0
C892 Direct Input 1 Default State 0 to 3 --- 1 F086 0 (Off)
C893 Direct Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
C894 ...Repeated for Direct Input 2
Table B–9: MODBUS MEMORY MAP (Sheet 50 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
