GE UR series

B-60 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
CA3C ...Repeated for Direct Output 23
CA3E ...Repeated for Direct Output 24
CA40 ...Repeated for Direct Output 25
CA42 ...Repeated for Direct Output 26
CA44 ...Repeated for Direct Output 27
CA46 ...Repeated for Direct Output 28
CA48 ...Repeated for Direct Output 29
CA4A ...Repeated for Direct Output 30
CA4C ...Repeated for Direct Output 31
CA4E ...Repeated for Direct Output 32
Direct Input/Output Alarms (Read/Write Setting)
CAD0 Direct Input/Output Channel 1 CRC Alarm Function 0 to 1 --- 1 F102 0 (Disabled)
CAD1 Direct I/O Channel 1 CRC Alarm Message Count 100 to 10000 --- 1 F001 600
CAD2 Direct Input/Output Channel 1 CRC Alarm Threshold 1 to 1000 --- 1 F001 10
CAD3 Direct Input/Output Channel 1 CRC Alarm Events 0 to 1 --- 1 F102 0 (Disabled)
CAD4 Reserved (4 items) 1 to 1000 --- 1 F001 10
CAD8 Direct Input/Output Channel 2 CRC Alarm Function 0 to 1 --- 1 F102 0 (Disabled)
CAD9 Direct I/O Channel 2 CRC Alarm Message Count 100 to 10000 --- 1 F001 600
CADA Direct Input/Output Channel 2 CRC Alarm Threshold 1 to 1000 --- 1 F001 10
CADB Direct Input/Output Channel 2 CRC Alarm Events 0 to 1 --- 1 F102 0 (Disabled)
CADC Reserved (4 items) 1 to 1000 --- 1 F001 10
CAE0 Direct I/O Ch 1 Unreturned Messages Alarm Function 0 to 1 --- 1 F102 0 (Disabled)
CAE1 Direct I/O Ch 1 Unreturned Messages Alarm Msg Count 100 to 10000 --- 1 F001 600
CAE2 Direct I/O Ch 1 Unreturned Messages Alarm Threshold 1 to 1000 --- 1 F001 10
CAE3 Direct I/O Ch 1 Unreturned Messages Alarm Events 0 to 1 --- 1 F102 0 (Disabled)
CAE4 Reserved (4 items) 1 to 1000 --- 1 F001 10
CAE8 Direct IO Ch 2 Unreturned Messages Alarm Function 0 to 1 --- 1 F102 0 (Disabled)
CAE9 Direct I/O Ch 2 Unreturned Messages Alarm Msg Count 100 to 10000 --- 1 F001 600
CAEA Direct I/O Ch 2 Unreturned Messages Alarm Threshold 1 to 1000 --- 1 F001 10
CAEB Direct I/O Channel 2 Unreturned Messages Alarm Events 0 to 1 --- 1 F102 0 (Disabled)
CAEC Reserved (4 items) --- --- 1 F001 10
Remote Devices (Read/Write Setting) (16 modules)
CB00 Remote Device 1 GSSE/GOOSE Application ID --- --- --- F209 “Remote Device 1“
CB21 Remote Device 1 GOOSE Ethernet APPID 0 to 16383 --- 1 F001 0
CB22 Remote Device 1 GOOSE Dataset 0 to 8 --- 1 F184 0 (Fixed)
CB23 ...Repeated for Device 2
CB46 ...Repeated for Device 3
CB69 ...Repeated for Device 4
CB8C ...Repeated for Device 5
CBAF ...Repeated for Device 6
CBD2 ...Repeated for Device 7
CBF5 ...Repeated for Device 8
CC18 ...Repeated for Device 9
CC3B ...Repeated for Device 10
CC5E ...Repeated for Device 11
CC81 ...Repeated for Device 12
CCA4 ...Repeated for Device 13
CCC7 ...Repeated for Device 14
CCEA ...Repeated for Device 15
CD0D ...Repeated for Device 16
Remote Inputs (Read/Write Setting) (64 modules)
CFA0 Remote Input 1 Device 1 to 16 --- 1 F001 1
CFA1 Remote Input 1 Item 0 to 64 --- 1 F156 0 (None)
CFA2 Remote Input 1 Default State 0 to 3 --- 1 F086 0 (Off)
Table B–9: MODBUS MEMORY MAP (Sheet 52 of 55)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
