GE UR series

GE Multilin L60 Line Phase Comparison System B-75
APPENDIX B B.4 MEMORY MAPPING
B
F208
TEXT2: 2-CHARACTER ASCII TEXT
F211
ENUMERATION: SOURCE SELECTION
0 = None, 1 = SRC 1, 2 = SRC 2, 3 = SRC 3, 4 = SRC 4,
5 = SRC 5, 6 = SRC 6
F212
ENUMERATION: 87PC SOURCE SELECTION
0 = 1 Source Current; 1 = Two Source Currents
F220
ENUMERATION: PUSHBUTTON MESSAGE PRIORITY
F222
ENUMERATION: TEST ENUMERATION
0 = Test Enumeration 0, 1 = Test Enumeration 1
F226
ENUMERATION: REMOTE INPUT/OUTPUT TRANSFER
METHOD
0 = None, 1 = GSSE, 2 = GOOSE
F227
ENUMERATION: RELAY SERVICE STATUS
0 = Unknown, 1 = Relay In Service, 2 = Relay Out Of Service
F230
ENUMERATION: DIRECTIONAL POLARIZING
0 = Voltage, 1 = Current, 2 = Dual
F231
ENUMERATION: POLARIZING VOLTAGE
0 = Calculated V0, 1 = Measured VX
F232
ENUMERATION: CONFIGURABLE GOOSE DATASET ITEMS
FOR TRANSMISSION
value priority
0Disabled
1 Normal
2 High Priority
value GOOSE dataset item
0None
1 GGIO1.ST.Ind1.q
2 GGIO1.ST.Ind1.stVal
3 GGIO1.ST.Ind2.q
4 GGIO1.ST.Ind2.stVal
↓↓
255 GGIO1.ST.Ind128.q
256 GGIO1.ST.Ind128.stVal
257 MMXU1.MX.TotW.mag.f
258 MMXU1.MX.TotVAr.mag.f
259 MMXU1.MX.TotVA.mag.f
260 MMXU1.MX.TotPF.mag.f
261 MMXU1.MX.Hz.mag.f
262 MMXU1.MX.PPV.phsAB.cVal.mag.f
263 MMXU1.MX.PPV.phsAB.cVal.ang.f
264 MMXU1.MX.PPV.phsBC.cVal.mag.f
265 MMXU1.MX.PPV.phsBC.cVal.ang.f
266 MMXU1.MX.PPV.phsCA.cVal.mag.f
267 MMXU1.MX.PPV.phsCA.cVal.ang.f
268 MMXU1.MX.PhV.phsA.cVal.mag.f
269 MMXU1.MX.PhV.phsA.cVal.ang.f
270 MMXU1.MX.PhV.phsB.cVal.mag.f
271 MMXU1.MX.PhV.phsB.cVal.ang.f
272 MMXU1.MX.PhV.phsC.cVal.mag.f
273 MMXU1.MX.PhV.phsC.cVal.ang.f
274 MMXU1.MX.A.phsA.cVal.mag.f
275 MMXU1.MX.A.phsA.cVal.ang.f
276 MMXU1.MX.A.phsB.cVal.mag.f
277 MMXU1.MX.A.phsB.cVal.ang.f
278 MMXU1.MX.A.phsC.cVal.mag.f
279 MMXU1.MX.A.phsC.cVal.ang.f
280 MMXU1.MX.A.neut.cVal.mag.f
281 MMXU1.MX.A.neut.cVal.ang.f
282 MMXU1.MX.W.phsA.cVal.mag.f
283 MMXU1.MX.W.phsB.cVal.mag.f
284 MMXU1.MX.W.phsC.cVal.mag.f
285 MMXU1.MX.VAr.phsA.cVal.mag.f
286 MMXU1.MX.VAr.phsB.cVal.mag.f
287 MMXU1.MX.VAr.phsC.cVal.mag.f
288 MMXU1.MX.VA.phsA.cVal.mag.f
289 MMXU1.MX.VA.phsB.cVal.mag.f
290 MMXU1.MX.VA.phsC.cVal.mag.f
291 MMXU1.MX.PF.phsA.cVal.mag.f
292 MMXU1.MX.PF.phsB.cVal.mag.f
293 MMXU1.MX.PF.phsC.cVal.mag.f
294 MMXU2.MX.TotW.mag.f
295 MMXU2.MX.TotVAr.mag.f
296 MMXU2.MX.TotVA.mag.f
297 MMXU2.MX.TotPF.mag.f
298 MMXU2.MX.Hz.mag.f
299 MMXU2.MX.PPV.phsAB.cVal.mag.f
300 MMXU2.MX.PPV.phsAB.cVal.ang.f
301 MMXU2.MX.PPV.phsBC.cVal.mag.f
302 MMXU2.MX.PPV.phsBC.cVal.ang.f
303 MMXU2.MX.PPV.phsCA.cVal.mag.f
304 MMXU2.MX.PPV.phsCA.cVal.ang.f
value GOOSE dataset item
