GE UR series

B-78 L60 Line Phase Comparison System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F233
ENUMERATION: CONFIGURABLE GOOSE DATASET ITEMS
FOR RECEPTION
F234
ENUMERATION: WATTMETRIC GROUND FAULT VOLTAGE
F235
ENUMERATION: WATTMETRIC GROUND FAULT CURRENT
F237
ENUMERATION: REAL TIME CLOCK MONTH
F238
ENUMERATION: REAL TIME CLOCK DAY
F239
ENUMERATION: REAL TIME CLOCK DAYLIGHT SAVINGS
TIME START DAY INSTANCE
F254
ENUMERATION: TEST MODE FUNCTION
F260
ENUMERATION: DATA LOGGER MODE
0 = Continuous, 1 = Trigger
value GOOSE dataset item
0None
1 GGIO3.ST.Ind1.q
2 GGIO3.ST.Ind1.stVal
3 GGIO3.ST.Ind2.q
4 GGIO3.ST.Ind2.stVal
↓↓
127 GGIO1.ST.Ind64q
128 GGIO1.ST.Ind64.stVal
129 GGIO3.MX.AnIn1.mag.f
130 GGIO3.MX.AnIn2.mag.f
131 GGIO3.MX.AnIn3.mag.f
132 GGIO3.MX.AnIn4.mag.f
133 GGIO3.MX.AnIn5.mag.f
134 GGIO3.MX.AnIn6.mag.f
135 GGIO3.MX.AnIn7.mag.f
136 GGIO3.MX.AnIn8.mag.f
137 GGIO3.MX.AnIn9.mag.f
138 GGIO3.MX.AnIn10.mag.f
139 GGIO3.MX.AnIn11.mag.f
140 GGIO3.MX.AnIn12.mag.f
141 GGIO3.MX.AnIn13.mag.f
142 GGIO3.MX.AnIn14.mag.f
143 GGIO3.MX.AnIn15.mag.f
144 GGIO3.MX.AnIn16.mag.f
145 GGIO3.ST.IndPos1.stVal
146 GGIO3.ST.IndPos2.stVal
147 GGIO3.ST.IndPos3.stVal
148 GGIO3.ST.IndPos4.stVal
149 GGIO3.ST.IndPos5.stVal
value voltage
0 Calculated VN
1 Measured VX
value current
0 Calculated IN
1 Measured IG
value month
0 January
1 February
2March
3April
4May
5June
6July
7 August
8 September
9 October
10 November
11 December
value day
0 Sunday
1 Monday
2 Tuesday
3 Wednesday
4 Thursday
5 Friday
6 Saturday
value instance
0First
1 Second
2Third
3Fourth
4Last
Value Function
0 Disabled
1 Isolated
2 Forcible
