34
Fn_24: Number of Auto-restart times = 0 up to 5
1. When Fn_24 = 0, the inverter will not try to restart.
(Except for momentary power loss, please refer to F_23 for details)
2. When Fn_24 > 0 , the inverter will resume operation via SPEED SEARCH at approximately
0.5 second after a function trip. After that, the inverter will accelerate or decelerate to current
frequency setting.
(Except for momentary power loss, please refer to F_23 for details)
3. When the inverter is set to deceleration or DC breaking, the transient restart procedure is not
performed.
4. When either of following situation happen, the transient restart count will be reset:
(1) No additional malfunction (in operation or stop) occurs within 10 minutes.
(2) Press RESET button or external terminal RESET is ON.
Fn_25 : Factory settings function
= 010 : Constants initialisation to 50Hz system
= 020 : Constants initialisation to 60Hz system
1. When Fn_25 is set to 010, all parameters are restored to factory settings. The settings of
Fn_05 =1 and Fn_06 = 50. Fn_25 is restored back to 000 after the reset process complete
(50Hz operation).
2. When Fn_25 is set to 020, all parameters are restored to factory settings. The settings of
Fn_05 =4 and Fn_06 = 60. Fn_25 is restored back to 000 after the reset process complete
(60Hz operation).
Fn_26: SP2 (1 up to 200Hz), multi-speed 2
(Refer to Fn_19, Fn_20)
Fn_27: SP3 (1 up to 200Hz), multi-speed 3
(Refer to Fn_19, Fn_20)
