Using Vscan Air CL
5-12 Vscan Air – User Manual
Direction GP092020-1EN
Rev 18
Storing an image/video
Refer to sections ‘Storing an image’ on page 5-30 and ‘Storing a
video’ on page 5-31.
Probe and Presets
Use of presets
To ensure optimal image quality, the Vscan Air ultrasound
system has predefined scanning settings optimized for different
applications. Refer to the tables below to select the correct
Vscan Air CL transducer and preset combination before
scanning.
Table 5-2: Curved array (deep scanning) transducer presets
Curved array
transducer Preset Optimized for
Abdominal • Liver
• Gall bladder and biliary tree
• Pancreas
• Spleen
• Kidneys
• Urinary Bladder
• Prostate
• Bowel
• Fluid detection
Cardiac • Heart
• Fluid detection
MSK Musculoskeletal (conventional)
• Joint
• Long bones
• Muscles, large tendons
• Deeper soft tissue structures
OB/Gyn • Obstetrics
• Uterus
• Fetus
• Placenta
• Amniotic fluid
• Gynecology
• Uterus including cervix
• Ovaries and adnexa
Vascular • Abdominal aorta
• IVC
• Other veins and arteries
Lung • Thoracic/Pleural motion
• Lung tissue
• Fluid detection
