Overview
Vscan Air – User Manual 1-7
Direction GP092020-1EN Rev 18
Indications for use (continued)
With the curved array transducer of the dual headed probe
solution, the specific clinical applications and exam types
include abdominal, fetal/obstetrics, gynecological, urology,
thoracic/lung, cardiac (adult and pediatric, 40 kg and above),
vascular/peripheral vascular, musculoskeletal (conventional),
pediatrics, interventional guidance (includes free hand needle/
catheter placement, fluid drainage, nerve block and biopsy).
With the linear array transducer of the dual headed probe
solution, the specific clinical applications and exam types
include: vascular/peripheral vascular, musculoskeletal
(conventional and superficial), small organs, thoracic/lung,
ophthalmic, pediatrics, neonatal cephalic, interventional
guidance (includes free hand needle/catheter placement, fluid
drainage, nerve block, vascular access and biopsy).
Table 1-3: Supported imaging modes
Vscan Air
Black/white
imaging (B-mode)
Color flow
(Color doppler)
Combined (B+
color doppler) Harmonics
Curved array
transducer
X XXX
Linear array
transducer
X XXX
• To avoid injury to the patient, select the Ophthalmic preset
when performing an eye exam.
• The system will not exceed the lower acoustic energy limits
for ophthalmic use only if the Ophthalmic preset is
selected.
• Be sure to use the linear array transducer for eye scanning.
