GEA Bock HG34e Series User Manual

D
GB
F
E
I
Ru
3
96178-06.2015-DGbFEIRu
Contents Page
3 Areas of application 8
 3.1 Refrigerants
 3.2 Oilcharge
 3.3 Limitsofapplication
 3.4 Refrigerants-designforR407C,35bar
 3.5 OilchargeforR407C,35bar
 3.6 LimitsofapplicationforR407C,35bar
4 Compressor assembly 12
 4.1 Storageandtransport
 4.2 Settingup
 4.3 Pipeconnections
 4.4 Pipes
 4.5 Layingsuctionandpressurelines
 4.6 Operatingtheshut-offvalves
 4.7 Operatingmodeofthelockableserviceconnections
5 Electrical connection 15
 5.1 Informationforcontactorandmotorcontactorselection
 5.2 Connectionofthedrivingmotor
 5.3 Circuitdiagramfordirectstart230VΔ/400VY-->with MP10
 5.4 ElectronictriggerunitMP10
 5.5 ConnectionoftheelectronictriggerunitMP10
 5.6 FunctionaltestoftheelectronictriggerunitMP10
 5.7 Circuitdiagramfordirectstart230VΔ/400VY-->with INT69 G
 5.8 ElectronictriggerunitINT69G
 5.9 ConnectionoftheelectronictriggerunitINT69G
 5.10 FunctionaltestoftheelectronictriggerunitINT69G
 5.11 Startunloader
6 Commissioning 24
 6.1 Preparationsforstart-up
 6.2 Pressurestrengthtest
 6.3 Leaktest
 6.4 Evacuation
 6.5 Refrigerantcharge
 6.6 Start-up
 6.7 Avoidingslugging
 6.8 Connectionofoillevelregulator
7 Maintenance 26
 7.1 Preparation
 7.2 Worktobecarriedout
 7.3 Sparepartsrecommendation
 7.4 Accessories
 7.5 Extractfromthelubricantstable
 7.6 Decommissioning
8 Technical data 28
9 Dimensions and connections 30
10 Declaration of conformity and installation 32
11 Service 33
