2| Product description
• Semi-hermeticfour-cylinderreciprocatingcompressorwithoilpumplubrication.
• Suctiongascooleddrivemotor.
2.1 Short description
DimensionandconnectionvaluescanbefoundinChapter9
Nameplate
Fig.1
Fig.2
Oilsightglass
Valveplate
Cylindercover
Discharge
shut-offvalve
Oilpump
Terminalbox
Suctionshut-
offvalve
Drivesection
Motorsection
Transporteyelet
