9| Dimensions and connections
SV
DV
Suctionline
Dischargeline
seetechnicaldata,Chapter8
A
Connectionsuctionside,

notlockable
1
/
8
“ NPTF
A1
Connectionsuctionside,

lockable
7
/
16
“UNF
B
Connectiondischargeside,

notlockable
1
/
8
“ NPTF
B1
Connectiondischargeside,lockable
7
/
1
6
“UNF
D1
Connectionoilreturnfromoilseparator
1
/
4
“ NPTF
E
Connectionoilpressuregauge
1
/
8
“ NPTF
F
Oildrain
M10
H
Oilchargeplug
1
/
4
“ NPTF
J1
O
ilsumpheater(accessories) Ø15mm
K
Sightglass
1
1
/
8
“-18UNEF
L1
Thermalprotectionthermostat
1
/
8
“ NPTF
O
Connectionoillevelregulator
1
1
/
8
“-18UNEF
Dimensionsinmm
Fig.25
1)
SV90°rotatable
1)
Centreofgravity
273
230
31046
ca.135
ca.165
79 419
F
A
H,D1
B1
E
L1
DV
J1
O,K
ca.315
272
115
4x 12
ca.285
BA
ca.540
A1
SV
A
10
40
30
M
20
Schwingungs-
dämpfer
273
230
31046
ca.135
ca.165
79 419
F
A
H,D1
B1
E
L1
DV
J1
O,K
ca.315
272
115
4x 12
ca.285
BA
ca.540
A1
SV
A
10
40
30
M
20
Schwingungs-
dämpfer
HG34e R407C
Vibration
damper
